Adapter coil - with 15P/24V plug (ISO 12098) and 7P/24V metal plug (ISO 1185)
Erich Jaeger 711113Genuine Erich Jaeger

Adapter coil - with 15P/24V plug (ISO 12098) and 7P/24V metal plug (ISO 1185)

Price on request

Lead time: within 1 week
Request quote

Official Erich Jaeger product page

ConnectorRoute is an authorized distributor of Erich Jaeger products. Article numbers of other brands are used for identification and cross-reference purposes only.

StandardISO 12098, ISO 1185 - Type N
Voltage24V
Poles7P, 15P
Categoryadapter

System products

Genuine Erich Jaeger parts that are often ordered together with this article: matching plugs, sockets, coil cables and adapters.

External article references

Known cross-reference numbers

These supplier, distributor and vehicle-brand references are used for identification only.

Brand / supplierReference numbers
Europart4830711113
Scania2022343

Product context

Product description and application

What does 711113 do?

Erich Jaeger 711113 is Adapter coil - with 15P/24V plug (ISO 12098) and 7P/24V metal plug (ISO 1185). In practice this adapter is selected by connector family, electrical standard, voltage, pole count and the way it is mounted or connected in the vehicle. ISO 12098, ISO 1185 - Type N and 24V should be verified against the vehicle or trailer wiring diagram.

Technical checks before ordering

The public product data highlights: Contact allocation: diagram 13, Working length [in m]: 3, Max. working length [in m]: 3,00, Max. extension length [in m]: 4,50, Type of seal: grommet, Description: with 15P/24V plug (ISO 12098) and 7P/24V metal plug (ISO 1185). These details matter because the right article description can still fail on cable entry, contact termination, sealing, housing material or installation space.

How ConnectorRoute supplies this article

As an authorized Erich Jaeger distributor, ConnectorRoute supplies 711113 new and genuine, in original manufacturer packaging. Goods are supplied in full boxes; your quote states the box quantity, per-piece price, availability and lead time.

Products that belong in the same order

Where possible, combine related system parts in one order: 141053 15P/24V Socket (ISO 12098 ADR), 241010 15P/24V Plug (ISO 12098 ADR), 541128 15P/24V supply cable - with supplementary 15P/24V socket (ISO 12098) and 2x 8P connector, 641167 15P/24V Coil (ISO 12098 ADR), 141168 15P/24V «JAEGER Basic» Socket (ISO 12098 ADR). That prevents solving one article number while leaving the matching plug, socket, coil cable or adapter as the next bottleneck.

Structured product facts

Article number
711113
Product family
adapter
Standard
ISO 12098, ISO 1185 - Type N
Voltage
24V
Poles
7P, 15P
Industry
commercial vehicles

Questions about this article

Is this a genuine Erich Jaeger part?

Yes. ConnectorRoute is an authorized Erich Jaeger distributor and supplies 711113 new and genuine, sourced directly from Erich Jaeger.

How is 711113 packaged and ordered?

Erich Jaeger parts are supplied in original manufacturer boxes. Orders are placed per box; the product page or quote states the box quantity and the per-piece price.

What should I send with an enquiry?

Send the Erich Jaeger article number and the quantities you need. For system advice, add photos of the installed part, the mating connector and vehicle or trailer information.

Technical specifications

Technical data

Contact allocation
diagram 13
Working length [in m]
3
Max. working length [in m]
3,00
Max. extension length [in m]
4,50
Type of seal
grommet
Description
with 15P/24V plug (ISO 12098) and 7P/24V metal plug (ISO 1185)
Product group
adapter
Standard
ISO 12098, ISO 1185 - Type N
Industry
commercial vehicles
Temperature resistance [in °C]
-40.0 - 85.0
Voltage [in V]
24
Packaging
without packaging
Cable color
black
Housing color
silver-colored
Housing material
break-proof metal
Cable outlet
grommet
No. of connected plugs
2
No. of connected sockets
0
No. of poles
07, 15
Outer coil diameter [in mm]
100,00
