Erich Jaeger 651017Genuine Erich Jaeger

Adapter coil - with 7P/12V plug (ISO 1724) and 7P/24V plug (ISO 1185)

Price on request

Lead time: within 1 week

ConnectorRoute is an authorized distributor of Erich Jaeger products. Article numbers of other brands are used for identification and cross-reference purposes only.

StandardISO 1185 - Type N, ISO 1724 - Type N

Voltage12V, 24V

Poles7P

Categoryadapter

External article references

Known cross-reference numbers

These supplier, distributor and vehicle-brand references are used for identification only.

Brand / supplier	Reference numbers
Bosch	`F032180225ZDB`
Europart	`9195200000`
Hella	`8KA 007 648-061`
Herth & Buss	`51276523`
Hofmei	`677800040`
Scania	`1 912 052`

Product context

Product description and application

What does 651017 do?

Erich Jaeger 651017 is Adapter coil - with 7P/12V plug (ISO 1724) and 7P/24V plug (ISO 1185). In practice this adapter is selected by connector family, electrical standard, voltage, pole count and the way it is mounted or connected in the vehicle. ISO 1185 - Type N, ISO 1724 - Type N and 12V, 24V should be verified against the vehicle or trailer wiring diagram.

Technical checks before ordering

The public product data highlights: Working length [in m]: 3, Max. working length [in m]: 3,00, Max. extension length [in m]: 4,50, Wire cross-sectional area: 6x 1.0mm² + 1x 1.5mm², Outer coil diameter [in mm]: 50,00, Description: with 7P/12V plug (ISO 1724) and 7P/24V plug (ISO 1185). These details matter because the right article description can still fail on cable entry, contact termination, sealing, housing material or installation space.

How ConnectorRoute supplies this article

As an authorized Erich Jaeger distributor, ConnectorRoute supplies 651017 new and genuine, in original manufacturer packaging. Goods are supplied in full boxes; your quote states the box quantity, per-piece price, availability and lead time.

Products that belong in the same order

Where possible, combine related system parts in one order: 101100 7P/12V Socket (ISO 1724 - Type N), 201212 7P/12V Plug (ISO 1724 - Type N), 511119 7P/24V supply cable - with 7P/24V socket (ISO 1185) and 8P connector (DIN 72580), 016271 7P coil (without plug/socket), 101285 7P/12V Socket (ISO 1724 - Type N). That prevents solving one article number while leaving the matching plug, socket, coil cable or adapter as the next bottleneck.

Structured product facts

Article number: 651017
Product family: adapter
Standard: ISO 1185 - Type N, ISO 1724 - Type N
Voltage: 12V, 24V
Poles: 7P
Industry: cars, agriculture, commercial vehicles

Questions about this article

Is this a genuine Erich Jaeger part?

Yes. ConnectorRoute is an authorized Erich Jaeger distributor and supplies 651017 new and genuine, sourced directly from Erich Jaeger.

How is 651017 packaged and ordered?

Erich Jaeger parts are supplied in original manufacturer boxes. Orders are placed per box; the product page or quote states the box quantity and the per-piece price.

What should I send with an enquiry?

Send the Erich Jaeger article number and the quantities you need. For system advice, add photos of the installed part, the mating connector and vehicle or trailer information.

Technical specifications

Technical data

Working length [in m]: 3
Max. working length [in m]: 3,00
Max. extension length [in m]: 4,50
Wire cross-sectional area: 6x 1.0mm² + 1x 1.5mm²
Outer coil diameter [in mm]: 50,00
Description: with 7P/12V plug (ISO 1724) and 7P/24V plug (ISO 1185)
Product group: adapter
Standard: ISO 1185 - Type N, ISO 1724 - Type N
Industry: cars, agriculture, commercial vehicles
Voltage [in V]: 12, 24
Packaging: without packaging
Special feature: requirements similar to ISO 4141-4
Cable color: black
Housing color: silver-colored
Housing material: break-proof metal
Cable outlet: cap nut
No. of connected plugs: 2
No. of connected sockets: 0
No. of poles: 07
