15P/24V Socket (ISO 12098 ADR)
Erich Jaeger 141050Genuine Erich Jaeger

15P/24V Socket (ISO 12098 ADR)

Price on request

Lead time: within 1 week
Request quote

Official Erich Jaeger product page

ConnectorRoute is an authorized distributor of Erich Jaeger products. Article numbers of other brands are used for identification and cross-reference purposes only.

StandardISO 12098
Voltage24V
Poles15P
Categorysocket

System products

Genuine Erich Jaeger parts that are often ordered together with this article: matching plugs, sockets, coil cables and adapters.

External article references

Known cross-reference numbers

These supplier, distributor and vehicle-brand references are used for identification only.

Brand / supplierReference numbers
Aspöck13-3170-067

Product context

Product description and application

What does 141050 do?

Erich Jaeger 141050 is 15P/24V Socket (ISO 12098 ADR). In practice this socket is selected by connector family, electrical standard, voltage, pole count and the way it is mounted or connected in the vehicle. ISO 12098 and 24V should be verified against the vehicle or trailer wiring diagram.

Technical checks before ordering

The public product data highlights: For cable diameter: 7,00mm - 9,00mm 7,00mm - 9,00mm, Contact termination: crimp contact, Protection: IP 54, Packaging: PE bag, No. of seal outlets: double, Standard: ISO 12098. These details matter because the right article description can still fail on cable entry, contact termination, sealing, housing material or installation space.

How ConnectorRoute supplies this article

As an authorized Erich Jaeger distributor, ConnectorRoute supplies 141050 new and genuine, in original manufacturer packaging. Goods are supplied in full boxes; your quote states the box quantity, per-piece price, availability and lead time.

Products that belong in the same order

Where possible, combine related system parts in one order: 541128 15P/24V supply cable - with supplementary 15P/24V socket (ISO 12098) and 2x 8P connector, 241010 15P/24V Plug (ISO 12098 ADR), 641167 15P/24V Coil (ISO 12098 ADR), 711110 Adapter coil - with 15P/24V plug (ISO 12098) and 2x 7P/24V metal plugs (ISO 1185 + ISO 3731), 541083 15P/24V supply cable - with supplementary 15P/24V socket (ISO 12098) and 2x 8P angular connector (DIN 72580). That prevents solving one article number while leaving the matching plug, socket, coil cable or adapter as the next bottleneck.

Structured product facts

Article number
141050
Product family
socket
Standard
ISO 12098
Voltage
24V
Poles
15P
Industry
commercial vehicles

Questions about this article

Is this a genuine Erich Jaeger part?

Yes. ConnectorRoute is an authorized Erich Jaeger distributor and supplies 141050 new and genuine, sourced directly from Erich Jaeger.

How is 141050 packaged and ordered?

Erich Jaeger parts are supplied in original manufacturer boxes. Orders are placed per box; the product page or quote states the box quantity and the per-piece price.

What should I send with an enquiry?

Send the Erich Jaeger article number and the quantities you need. For system advice, add photos of the installed part, the mating connector and vehicle or trailer information.

Technical specifications

Technical data

For cable diameter
7,00mm - 9,00mm 7,00mm - 9,00mm
Contact termination
crimp contact
Protection
IP 54
Packaging
PE bag
No. of seal outlets
double
Product group
socket
Standard
ISO 12098
Industry
commercial vehicles
Voltage [in V]
24
Included in delivery
crimp contact pins (3x 2.5mm² + 12x 1.0-1.5mm²)
Type of seal
screw cap
Cover insert color
red
Cover material
reinforced composite
Housing color
black
Housing material
reinforced composite
Cable outlet
bayonet coupling, cable outlet 180°, cap nut
No. of poles
15
Addition to standard
ADR
