W2P · DTOriginal brand part
W2P
DEUTSCH DT wedgelock for receptacles
Green secondary lock that holds the pin contacts in the DT04 receptacle — one per housing
All part numbers in this family · 15
Part number W2PConnectorRoute SKU CR-CN-000083
Business price · excl. VAT
€0.09per piece
Quantity pricing — click a tier to set the quantity
Lead time: 1–2 weeks
Free shipping from €500 · below that €25 flat
Current rating13 A
Wire range0.5–2.0 mm² (20–14 AWG)
SealingIP67 / IP68 / IP6K9K
Temperature-55 °C … +125 °C
Goes with this part
Frequently ordered together with W2P
Exactly the parts that fit the selected part number — quantities per housing are indicated.
Brand and references
Part numbers and cross-references
Original manufacturer numbers of this family. Use them to match the article in your drawing, BOM or existing supplier system.
| Brand | Part numbers |
|---|---|
| DEUTSCH (TE Connectivity) | W2P, W3P, W4P, W6P, W8P, W12P, W2PA, W2PB, W2PC, W2PD, W4PA, W4PB, W4PC, W4PD, W3P-1939 |
| TE Connectivity | TE part numbers are the original DEUTSCH numbers (DEUTSCH is a TE brand since 2012) |
Product context
Where this connector is used
DT in the truck, trailer and agricultural world
Lighting, sensors, EBS/ABS modulators, tail-lift and refrigeration controls, body-builder and agricultural implement wiring. The 2- and 4-way DT is the connector you find on nearly every trailer lamp and sensor; 8- and 12-way keyed versions handle module and harness-to-harness connections.
Original parts, system supply
ConnectorRoute supplies the original TE Connectivity / DEUTSCH parts, not compatibles. Housings, wedgelocks, contacts, seals, tools and the matching FLRY-B cable come from one source, so a harness shop or trailer builder can order the complete connection per drawing position.
Ordering and lead time
Housings and wedgelocks are sold per piece; contacts, seals and plugs in packs of 100. Priced articles go straight into the cart; for project volumes or unpriced numbers request a quote and we confirm price and lead time by mail.
Structured product facts
- Brand
- DEUTSCH (TE Connectivity)
- Part number
- W2P, W3P, W4P, W6P, W8P, W12P
- Product type
- Wedgelock
- Sales unit
- per piece
Questions about this connector
Is this an original DEUTSCH part?
Yes. Every part number on this page is an original TE Connectivity part (DEUTSCH brand), supplied through the official distribution channel. We do not sell compatible copies.
What else do I need for a complete connection?
See the system products above: housings, wedgelocks, contacts and tools of the same series.
Which cable and crimp tool go with it?
FLRY-B thin-wall vehicle cable in the cross-sections of the contact wire range; ConnectorRoute stocks it on 50/100/500 m spools. Crimp tools of this series are listed under system products.
Technical specifications
Technical data
- Brand
- DEUTSCH (TE Connectivity)
- Product type
- Wedgelock
- Contact size
- 16
- Current rating
- 13 A
- Wire range
- 0.5–2.0 mm² (20–14 AWG)
- Sealing
- IP67 / IP68 / IP6K9K
- Temperature
- -55 °C … +125 °C
- Voltage
- 250 V AC/DC (12/24/48 V systems)
- Positions
- 2, 3, 4, 6, 8, 12
- Pitch
- 5.46 mm
- Mating cycles
- 100
- Materials
- PA GF housing, silicone seals, copper-alloy contacts nickel or gold plated
- Sales unit
- per piece
