€16.20 per piece · box of 350ISO 11446 · 13-core, 12 V (ISO 11446)Generic standard cable
13-core trailer cable ISO 11446 13-core, 12 V (ISO 11446)
12 V 13-pin cable, 8 x 1.5 + 5 x 2.5 mm² — trailers, caravans, light commercial
Colour
Spool length
Article: CR-CB-001026
Business price · excl. VAT
€209.40per spool
Lead time: 1–2 weeks
Free shipping from €500 · below that €25 flat
1
ConnectorRoute supplies standard-compliant vehicle cable from European manufacturers. Article numbers of other brands are used for identification and cross-reference purposes only.
Construction8 x 1.5 + 5 x 2.5 mm²
Number of cores13 cores
Temperature range-40 °C … +105 °C
StandardISO 11446
SKUs
Colours, lengths and article numbers
One article number per colour and spool length. Prices are per spool, excl. VAT.
| Colour | Spool | ConnectorRoute SKU | Price / spool |
|---|---|---|---|
| black | 50 m | CR-CB-001026 | €209.40 €4.19 per m |
| black | 100 m | CR-CB-001027 | €418.81 €4.19 per m |
System products
Frequently ordered together
The connectors, sockets and coil cables that this cable is terminated to, plus neighbouring cross-sections of the same type.
€16.20 per piece · box of 350
Price on requestView product
€22.95 per piece · box of 100
€20.05 per piece · box of 100Standard and references
Standard and OE reference numbers
Manufactured to the standard below. Where vehicle and trailer builders list this cable under their own part number, those OE numbers are shown so you can identify the article in your system.
| Standard / OE brand | Reference |
|---|---|
| Standard | ISO 11446 |
Product context
Application and selection
What is ISO 11446?
Fixed wiring for 12 V trailers, caravans, horse boxes and light commercial trailers with the 13-pin ISO 11446 system: lighting on the 1.5 mm² cores, permanent supply, charging line and earth on the 2.5 mm² cores. Pairs with 13-pin plugs and sockets.
How to choose the cross-section
Select the conductor cross-section on the current of the circuit and the cable length: 0.35–1.0 mm² for signals and sensors, 1.5–2.5 mm² for lighting and most control circuits, 4.0–6.0 mm² for high-load consumers, and 10 mm² and above for supply, battery and earth leads. When in doubt, go one size up — voltage drop on 24 V trailers is a common cause of lighting faults.
How ConnectorRoute supplies this cable
Standard-compliant cable from European manufacturers, delivered on spools of 50 / 100 m. Colours and cross-sections are stocked as standard articles; larger volumes, cut lengths and drum quantities are quoted on request. Prices are per spool, excl. VAT, for business customers.
Structured product facts
- Article
- CR-CB-001026
- Standard
- ISO 11446
- Construction
- 8 x 1.5 + 5 x 2.5 mm²
- Colours
- 1
- Spool lengths
- 50 / 100 m
Questions about this cable
Is this original-brand cable?
This is generic cable manufactured to ISO 11446. It is manufacturer-independent: the specification, not the brand, is what your harness or approval requires. OE numbers of vehicle builders are listed for identification where known.
Can I order less than a full spool?
The standard sales units are 50 / 100 m spools. Cut lengths and drum quantities are possible on request — send the type, cross-section, colour and length to ConnectorRoute.
Which connector does this cable belong to?
This cable is designed for the ISO 11446 connectors: the core count and colours match the pin assignment of the corresponding Erich Jaeger plugs and sockets shown under 'Frequently ordered together'.
Technical specifications
Technical data
- Standard
- ISO 11446
- Construction
- 8 x 1.5 + 5 x 2.5 mm²
- Number of cores
- 13
- Insulation
- PVC / PVC sheath
- Wall thickness
- thin-wall
- Temperature range
- -40 °C … +105 °C
- Rated voltage
- 12 V DC
- Conductor
- bare copper, fine-stranded (class 5), ISO 11446 core colours
- Colours
- black
- Spool lengths
- 50 / 100 m
- Sales unit
- spool
